| ►Interface: | BNC connector to 10 Base-2 | ►Technique: | Baseband |
| BNC connector to 10 Base-2 | ►Topology: | Daisy Chain | |
| ►Cable length: | 185 M maximum per Thin Coaxial cables. | ||
| ►External Power: | Input 110V or 220V AC Output 12V DC, 1 Amp | ►Dimensions: | 0.8" (H) x 2.2" (W) x 4.2" (D) |
| ►Temperature: | 0 to 55C (standard operating) | ►LAN Expansion | Coaxial expand upon to 30 Daisy Chain |
| ►Humidity: | 10 to 90% (non-condensing) | ||
| ►Standard: | IEEE 802.3 10Base-T/10Base-2 | ||
| ►EMI: | Meets FCC Class A Subpart B of Part 15 Requirement | ||
